4 Poles + Ground

M26R

M26R

Model

M26R

2011
Knife switche:Knife switches 4 Poles + Ground
Rated voltage:400V (300V DC)
Rated current:20A (14A DC)
Working temperature:T 120°C (T240°C M26RH)
Impulse voltage:5 kV
Type of clamps for the cables connection:bush + screw clamps
Clamps connecting capacity:0.75 ÷ 2.50 mm² (UL 18 ÷ 12 AWG)
Overvoltage category:III
Pollution degree:II
Protection grade:IP20
In conformity to the standards:EN 60598 (UL 1059 - CSA C22.2 No.158-10)
Approval marks:C.S.v. IMQ
UL - Working temperature:T 120°C (T220°C M26RH)
UL - Rated voltage:300V
UL - Rated current:17A
UL - Approval marks:cURus
Body: PA66
